Products
Magnetic Stirrers with Hot Plates
Precision Mixing and Controlled Heating for Modern Laboratories
Athena Instruments introduces its range of Magnetic Stirrers with Hot Plates, precision-engineered for consistent mixing and reliable temperature control in chemical, pharmaceutical, biological, and industrial laboratories. Designed with brushless DC motors, durable work plates, and advanced digital or encoder controls, these instruments deliver quiet, smooth, and maintenance-free operation, ensuring reproducible results for a wide range of laboratory applications.
Available in multiple models with heating options, programmable timers, and digital interfaces, Athena’s stirrers support stirring volumes up to 3 liters and speeds from 200 to 1600 rpm. Compact and user-friendly, they are ideal for chemical synthesis, QA/QC testing, drug formulation, academic research, and small-scale industrial R&D.
Key Features :
- High-Grade Construction: Durable hot plate or tempered glass surfaces, chemically resistant and easy to clean.
- Advanced Drive System From 0.1 to 200 RPM with up to 54 selectable speeds for diverse application requirements;
- Flexible Speed Control: Stepless encoder or digital adjustment across 200–1600 rpm for precise stirring.
- Temperature Control: Heating models offer accurate regulation up to 300°C.
- Digital Monitoring: Backlit LCD display (select models) shows real-time set and actual values.
- Programmable Timer: Supports experiment durations up to 99h 59min.
- Compact & Ergonomic: Space-saving design with intuitive controls for efficient bench use.
- Safety Features: Overheat protection, spill-resistant design, and chemical-resistant coating.
Applications
Chemical & Analytical Labs
Reagent prep, compound synthesis, pH titration, and buffer solutions.
Pharmaceuticals
Drug formulation, dissolution testing, and QA/QC lab analysis.
Food &
Beverage
Sample agitation, compositional testing, and solution homogenization.
Process
R&D
Continuous mixing and temperature-controlled experiments in pilot labs.
Academic Research
Ideal for classroom experiments and university-level research protocols.
Product Models & Specifications
| Model |
Type |
Display |
Work Plate |
Max Volume |
Heating |
Speed Range |
|---|---|---|---|---|---|---|
|
AT-85 |
Magnetic Stirrer |
Backlit LCD |
Tempered Glass |
3 L |
No |
200–1600 rpm |
| AT-87 | Magnetic Stirrer with Hot Plate | Encoder Control | Durable Hot Plate | 3 L | Yes |
200–1600 rpm |
| AT-86 | Digital Magnetic Stirrer |
Backlit LCD |
Tempered Glass |
3 L |
No | 200–1600 rpm |
| AT-88 |
Digital Magnetic Stirrer with Hot Plate |
Backlit LCD |
Durable Hot Plate |
3 L |
Yes |
200–1600 rpm |
Additional Technical Highlights
Motor Type
DC Brushless, low noise, maintenance-free, encoder-controlled for long life and precision speed.
Surface Options
Tempered glass or hot plate, corrosion and spill-resistant
Temperature Range (heating models)
RT to 300°C
Noise Level
Low-noise operation (<40 dB) for quiet lab environments
Control Modes
Manual/encoder with digital or analog interface
Safety Features
Overheat protection, chemical-resistant coating
Max Stirring Volume
3 Liters
Why Choose Athena’s Magnetic Stirrers with Hot Plates?
Trusted Performance, Certified Quality
Manufactured under ISO 9001:2015 compliant protocols and CE certified, Athena’s Magnetic Stirrers with Hot Plates provide lab-ready precision, safety, and durability. Trusted across academic institutions and industries, they combine innovation, efficiency, and reliability for modern laboratories.
