Orbital Shaking Incubator
High-Performance Temperature-Controlled Shaking Chamber for Life Sciences and Biotech Applications
Athena Instruments introduces the Orbital Shaking Incubator, a robust and precision-engineered laboratory system specifically designed for the simultaneous incubation and agitation of biological samples. Engineered to deliver uniform temperature distribution and programmable orbital shaking, this unit is ideal for fermentation, cell culture, enzymatic reactions, molecular biology, and pharmaceutical R&D.
Crafted with SS316 stainless steel interiors, PID-based temperature control, and a variable-speed shaking platform, Athena’s Orbital Shaking Incubator ensures reliable, consistent, and contamination-free performance across research and production environments.
Key Features :
- High-Grade Construction: Built with a double-walled body featuring an SS316 stainless steel inner chamber and a powder-coated CRCA outer casing. Insulated with high-density glass wool to reduce heat loss and maintain consistent temperature.
- Wide Temperature Range: Operates from 5°C to 60°C, suitable for microbial growth, biochemical studies, and cell line incubation. Maintains stability with ±0.5°C accuracy using a PT-100 sensor.
- Dual Heating & Cooling System:
- Heating via long-life SS air heaters
- Cooling with Emerson Copeland hermetically sealed compressor
- Uses CFC-free R-134A refrigerant for eco-friendly performance
- Over-temperature cutoff system activates at 70°C for enhanced safety
- Advanced Orbital Shaking Mechanism:
- Speed range: 20–250 RPM, controlled by a digital RPM indicator
- Shaking amplitude: 25 mm
- Powered by a PMDC geared motor for vibration-free, consistent motion
- Built-in 999-minute digital timer with audio-visual alarm for timed experiments
- Universal Platform Compatibility:
- Accepts removable SS lotus clamps for flasks ranging from 100 ml to 1000 ml
- Adjustable SS rod shelves allow flexible storage of Petri dishes, bottles, and tubes
- Interchangeable platform configuration available upon request
- Enhanced Visibility & Access:
- Toughened glass viewing window and internal illumination lamp for real-time sample observation
- Lockable insulated door with magnetic gasket ensures airtight sealing and minimal thermal loss
Applications
Biotechnology & Life Sciences
Reliable for bacterial, fungal, yeast, and mammalian cell cultures.
Pharmaceutical R&D:
Ideal for fermentation, drug stability testing, and enzymatic activity studies.
Molecular
Biology
Supports DNA/RNA hybridization, gene expression studies, and protein analysis.
Environmental & Agricultural Research
Suitable for seed germination, soil testing, and plant tissue culture.
Academic & Industrial Labs
Adaptable for teaching labs and research environments requiring programmable thermal and motion control.
Product Models & Specifications
|
Model Name |
Volume | Platform Size | Shaking Capacity | Trays | Max Flask Capacity |
|---|---|---|---|---|---|
|
ATOSI-1 |
100 Ltrs |
350 × 350 mm |
5 Liters |
1 |
100 ml – 16 |
| ATOSI-2 | 200 Ltrs | 450 × 450 mm | 10 Liters | 2 |
100 ml – 25 |
- Note: Stainless steel lotus clamps are optional and must be ordered separately. Custom tray layouts available on request.
Additional Technical Highlights
Material of Construction
SS316 inner chamber, CRCA powder-coated exterior
Shaking Drive
PMDC geared motor with variable speed control
Sealing Mechanism
Gasket-sealed insulated door with locking mechanism
Air Circulation
Motorized blower ensures uniform temperature across the chamber
Power Supply
Operates on 230V AC, 50 Hz, single phase
User Interface
Microprocessor-based controller with separate displays for RPM and temperature
Why Choose Athena’s Orbital Shaker?
Trusted Performance, Certified Quality
Athena’s Orbital Shaking Incubators are CE certified, ISO 9001:2015 compliant, and built under strict quality protocols to deliver field-tested reliability with global certification and long-term operational safety.
